GP-T1880
GP-T1880
Customization Options
Color Available in standard shades, with full customization options to match branding or environmental needs, including custom printing or relief logos on the enclosure.
Materials Fully customizable based on deployment environment:
Indoor: Options include standard ABS for cost-effective performance or V0 flame-retardant ABS (UL 94 V-0 rated) for enhanced fire safety in enclosed spaces.
Outdoor: PC/ABS blend is recommended for superior UV resistance, impact strength, and weatherproofing, ensuring long-term reliability in harsh conditions.
Features & Benifits
The GP-T1880 supports true 1-in / 1-out inline routing for Ø3 mm round drop cables with minimal bending.
It accommodates 1 SC simplex or LC duplex adapter for direct patching to customer equipment.
Integrated splice holder secures up to 6 heat-shrink fusion splices for reliable protection.
Ultra-slim 22 mm profile and 188 × 88 mm footprint fit easily in confined spaces.
High-impact ABS housing with optional UL94-V0 flame-retardant rating ensures safety.
Wide operating temperature range from -40°C to +70°C guarantees long-term stability.
Tool-less snap-lock cover allows quick opening without special tools.
Multiple cable entry knock-outs (rear and bottom) provide installation flexibility.
Clean white or black finish (custom colors available) matches any interior design.
Backed by Fibermint’s 2-year warranty and lifetime technical support.
Specification
Part No. | GP-T1880 |
Dimensions (L×W×H) | 188 × 88 × 22 mm |
Material | ABS (UL94 V0 Optional) |
Mounting | Wall Mount |
| IP Rating | IP20 |
Cable Entries | 1 / 1 In-line Ports |
Supported Cable | Ø3 mm Round Drop Cable |
Splicing Capacity | 6 Fibers |
Splicing Method | Fusion Splice |
| Operating Temperature | -40°C to +70°C |
Packing List
| Carton Capacity | 100 PCS/CTN |
| Carton G.W. | 20 KG |
| Carton Size | 53×31×41CM |
