GJS-H3346C
GJS-H3346C
The GJS-H3346C is a robust In-line Fiber Optic Splice Closure (FOSC) engineered for high-density fiber management. Constructed from high-quality PC/PP engineering plastics, it offers exceptional anti-aging and anti-corrosion properties against acids and alkaline salts.
High Capacity: Supports up to 144 single-core fibers with a maximum of 6 splice trays (24 cores per tray).
Superior Sealing: Features a dual-sealing system with silicon rubber for the shell and rubber seals for the 6 inlet/outlet ports (3-in/3-out).
IP68 Waterproof Rating: Guaranteed performance in serious working environments and intensive climate changes.
Optimized Fiber Protection: Splice trays (FOST) operate like booklets with a 40mm curvature radius to ensure signal integrity.
Flexible Cable Entry: Accommodates cable diameters ranging from 8mm to 22mm.
Maintenance Friendly: The mechanical structure allows for easy re-entry and reuse after installation without specialized tools.
Extreme Temperature Resistance: Operates reliably in temperatures ranging from -40°C to +60°C.
Part No. | GJS-H3346C |
Dimensions | 460×190×120 mm (19.49×6.89×5.12 in) |
Enclosure Material | MPP or PC |
| Cable Sealing Method | Rubber Grommet |
| Cable Entry/Exit Ports | 3 / 3 (In-line) |
| Cable Port Diameter | Ø8 - 22 mm |
| Splicing Capacity | 144 Fibers (Single-core) |
| Number of Trays | 6 Trays |
| Tray Material | ABS |
| Inflating Valve | Pre-installed (Optional) |
| Grounding Device | Pre-installed (Optional) |
IP Rating | IP68 |
Mounting | Aerial / Direct-buried |
| Carton Capacity | 10 PCS/CTN |
| Carton G.W. | 26 KG |
| Carton Size | 62×48×42CM |
A: The GJS-H3346C can accommodate up to 144 single-core fibers by installing a maximum of 6 splice trays, with each tray holding 24 fibers.
A: Yes, the GJS-H3346C is designed for multiple environments, including buried, aerial, and pipe/duct applications.
A: Absolutely. It has an IP68 protection grade and utilizes high-quality silicon rubber seals to prevent moisture ingress.
A: The 3-in/3-out ports are compatible with optical cables ranging from 8mm to 22mm in diameter.
A: Yes, the mechanical structure is designed to be opened and reused multiple times after the initial installation.
