FAT-FF8N2 Hardened MST - 8/9-Port Multi-Service Terminal with Corning OptiTap Compatibility

FAT-FF8N2 Hardened MST - 8/9-Port Multi-Service Terminal

Application

Streamlined FTTH Deployment: Engineered as a high-efficiency drop point for residential and commercial fiber networks, enabling high-speed subscriber activation with minimal field labor.
Harsh Environment Connectivity: Purpose-built for Outside Plant (OSP) applications, ensuring long-term reliability in extreme aerial and underground conditions. Versatile
Infrastructure Support: Optimized for multi-scenario installations, including direct wall-mount, utility pole-mount, and aerial strand-based deployments.

Capacities

Splicing Capacity: 16 Fibers
Patching Capacity: 8 or 9 SC or LC Duplex Adapters
Splitter Capacity: 1×8 or 1×9 Micro PLC Splitter


Availability:



Inquiry Now！ Add to Basket Product Catalog

Model:
FAT-FF8N2
Download:
FAT-FF8N2 Datasheet.pdf
Model:
FAT-FF8N2

Features & Benifits

Specification

Packing List

Documentation

FAQ

Features & Benifits

Superior Hardened Connectivity: Equipped with 10 industry-standard hardened adapter ports (8 top, 1 front, 1 rear), providing an environment-sealed interface for rapid "plug-and-play" service delivery.
Integrated Splicing & Splitting: Supports up to 16F single fusion splicing and includes dedicated slots for 1x8 or 1x9 unbalanced PLC splitters to accommodate diverse network architectures.
Rugged IP68 Protection: The PC+ABS clamshell design features a superior gasket seal to protect internal components against water and dust ingress in the most demanding environments.
No Specialized Tools Required: The pre-terminated adapter design eliminates the need for field splicing during the final drop connection, significantly reducing installation complexity.
Modular Management: Includes an internal SC adapter bracket for flexible patching and simplified testing during network maintenance.

Note: Adapters, pigtails, and splitters sold separately. Custom configurations available upon request.

Specification

Part No.	FAT-FF8N2
Dimensions (L×W×H)	336×102×93mm
Enclosure Material	MPP or PC +ABS
Box Sealing Method	Silicone Gaskets + Screw Lock
Cable Sealing Type	PG Gland or Hardened Connector
Cable Entry Ports	1 Port × CORNING Compatible Water-proof Adapters
Cable Exit Ports	8 or 9 Ports× CORNING Compatible Water-proof Adapters
Patching Capacity	8 or 9 SC or LC Duplex Adapters
Splicing Capacity	16 Fibers (Single-core)
Suitable Splitter	1×8 or 1×9 Micro PLC Splitter
IP Rating	IP68
Mounting	Aerial / Wall Mount / Pole Mount

Packing List

Carton Capacity	20 PCS/CTN
Carton G.W.	15 KG
Carton Size	46×40×53 CM

FAT-FF8N2 Datasheet.pdf

Fibermint 2025 Fiber OpticProduct Catalog.pdf

FAQ

Q1: What type of connectors are compatible with the FAT-FF8N2 ports?

A: The terminal is designed with ports compatible with industry-standard hardened connectors (H-Connectors), ensuring a secure, weather-proof connection for pre-terminated drop cables.

Q2: Is the terminal suitable for extreme outdoor weather?

A: Yes. The FAT-FF8N2 is constructed from UV-resistant PC+ABS material and is IP68-rated, making it fully submersible and resistant to dust and moisture.

Q3: Does the package include mounting hardware?

A: Every unit comes with a comprehensive accessory kit, including hardware for wall, pole ($\varnothing216$ mm), and aerial strand mounting to suit your specific installation needs.

Q4: Can I customize the internal splitter or adapter configuration?

A: Absolutely. While standard configurations include 1x8 or 1x9 unbalanced splitters, we support custom configurations and "fully loaded" options with SC or LC adapters upon request.
