FDB-16Q1-16A
FDB-16Q1-16A Datasheet.pdf
The 16Q Series Comparison
Features & Benifits
Durable engineering plastic enclosure ensures long-lasting performance in challenging conditions.
Supports a single splice tray with a 16-fiber capacity for efficient fiber organization.
Adapter frame accommodates up to 16 SC adapters, enabling high-density connectivity.
Mid-span port design allows for loop-through cable configurations, enhancing flexibility.
IP65 rating provides superior protection against dust and water ingress.
Compact and lightweight, simplifying installation in space-constrained environments.
Versatile mounting options (wall or pole) cater to various installation scenarios.
Note: Adapters, pigtails, and splitters sold separately. Custom configurations available upon request.
Specification
Part No.
Dimensions (L×W×H)
288×172×103mm
Enclosure Material
PC+ABS
Box Sealing Method
Silicone Gaskets + Snap-fit + Screw Lock
Cable Sealing Type
Grommet
Cable Entry Ports
16 Drop ports × Ø2-4.6mm
Patching Capacity (Max)
Splicing Capacity (Max)
Max Splice Trays
2 Trays
Tray Material
ABS
IP Rating
IP65
Mounting
Wall Mount / Pole Mount
Packing List
62×41×35 CM
